Find Most Common Color in an Image with Python

written by Andrew Shay on 2019-04-25

A while ago I wanted my Philips Hue light bulbs to change colors based on the most common color on my monitor.
I thought this would be cool when playing video games, which it is!

In this article I will explain a simple way for detecting the most common color in an image using Python.

Note: This article describes my method that I came up with for fun. It is not "the right way" to do this, the fastest, or most efficient. But it is simple!

Pixels

An image is made up of individual pixels. Each pixel is a color.
To find the most common color we can simply loop through every pixel, get the color, and keep a count of how many times the color appears.

I found an issue where for instance the color green and just barely slightly darker green are technically two different colors.
I couldn't see the difference between these two colors though, so I want them to be counted as a single color.
I need similar colors to be counted together because there are too many possible colors.

RGB

A color can be represented in RGB. RGB stands for RED GREEN BLUE.
An integer from 0 through 255 is used to represent R, G, and B. e.g. 255, 7, 125.
There are 16,777,216 total possible colors represented by RGB.
0 is no color (i.e. black) and 255 is all color.
0, 0, 0 would be black and 255, 255, 255 would be white.
So 0, 0, 255 would be no red, no green, and all blue.
0, 0, 254 would be just slightly darker blue, but not even perceptible.

Allowed RGB Values

What I decided to do was to create a set of "allowed" integers for R, G, and B.
I would then look at the actual integer, determine which allowed integer it was closest to, and change it to that.
This integer "snapping" technically changes the color of the pixel, but it greatly reduces the possible colors that can occur.
The pixels almost always still represent the correct color so determining the most common color is much simpler.

A decent set of evenly distributed allowed integers is [255, 223, 191, 159, 127, 95, 63, 31, 0].
This reduces our total possible color count to 729.
Let's say we have two pixels 254, 120, 5 and 250, 126, 20.
After we snap the integers we get 255, 127, 0 for both pixels.
We took two technically different colors and made them the same so they are counted together.

If you're looking for "color" you can also remove black, white and gray, from the count.

Python Script

Let's take a look at the code.
This is a simple straight forward script that can be read from top to bottom.
The Pillow library handles working with the images.
pip install pillow

import os

from PIL import Image

# Open image and get data
image_path = r"IMAGE_PATH.jpg"
img = Image.open(image_path)
width, height = img.size

# The RGB values we will "snap" to
colors = [255, 223, 191, 159, 127, 95, 63, 31, 0]

original_color_count = {}
color_count = {}
# Loop through every pixel in the image and modify it
for w in range(width):
    for h in range(height):
        current_color = img.getpixel((w, h))

        if current_color in original_color_count:
            original_color_count[current_color] += 1
        else:
            original_color_count[current_color] = 1

        r, g, b = current_color
        r_set = False
        g_set = False
        b_set = False

        #  Loop through our allowed values and find the closest value to snap to
        for i in range(len(colors)):
            color_one = colors[i]
            color_two = colors[i + 1]

            if not r_set:
                if color_one >= r >= color_two:
                    distance_one = color_one - r
                    distance_two = r - color_two
                    r = color_one if distance_one <= distance_two else color_two
                    r_set = True

            if not g_set:
                if color_one >= g >= color_two:
                    distance_one = color_one - g
                    distance_two = g - color_two
                    g = color_one if distance_one <= distance_two else color_two
                    g_set = True

            if not b_set:
                if color_one >= b >= color_two:
                    distance_one = color_one - b
                    distance_two = b - color_two
                    b = color_one if distance_one <= distance_two else color_two
                    b_set = True

            if all((r_set, g_set, b_set)):
                break

        # Set our new pixel back on the image to see the difference
        new_rgb = (r, g, b)
        img.putpixel((w, h), new_rgb)

        if new_rgb in color_count:
            color_count[new_rgb] += 1
        else:
            color_count[new_rgb] = 1

# Save our new image
filename, file_extension = os.path.splitext(image_path)
new_path = "{}_new{}".format(filename, '.png')
img.save(new_path)

# Count and sort the colors
all_colors = color_count.items()
all_colors = sorted(all_colors, key=lambda tup: tup[1], reverse=True)

# Print out the colors
print("## All Colors ##")
for i in range(10):
    print(all_colors[i])

# Remove black, white and gray
print("\n## All Colors Filtered ##")
filtered_colors = [color for color in all_colors if not color[0][0] == color[0][1] == color[0][2]]
for i in range(10):
    print(filtered_colors[i])

print("")
original_color_count = len(original_color_count)
print("Original Color Count: {}".format(original_color_count))
new_color_count = len(color_count)
print("New Color Count: {}".format(new_color_count))
color_diff = original_color_count - new_color_count
print("Reduced Color Count By: {}".format(color_diff))

Examples

Let's compare the changes using some images that I found on Unsplash.

Jungle

Photo by Jacob Plumb on Unsplash
https://unsplash.com/photos/UghHZmnJw58



Top 3 Colors
RGB: 0, 31, 0 Count: 61,167
RGB: 0, 0, 0 Count: 36,716
RGB: 31, 31, 31 Count: 23,208

Original Color Count: 62,963
New Color Count: 167
Reduced Color Count By: 62,796

Airplane Cockpit

Photo by JC Gellidon on Unsplash
https://unsplash.com/photos/7KFVkL1cV0w



Top 3 Colors
RGB: 31, 31, 31 Count: 166,090
RGB: 63, 63, 63 Count: 28,134
RGB: 255, 255, 255 Count: 4,943

Original Color Count: 21,216
New Color Count: 168
Reduced Color Count By: 21,048

Train Station

Photo by Patrick Schöpflin on Unsplash
https://unsplash.com/photos/BnlNjW3AQZ0



Top 3 Colors
RGB: 31, 31, 31 Count: 57,880
RGB: 63, 63, 63 Count: 29,510
RGB: 0, 0, 0 Count: 27,606

Original Color Count: 31,211
New Color Count: 117
Reduced Color Count By: 31,094

Summary

  • Loop through every pixel
  • Snap the RGB values to a smaller subset
  • Count each color

Pillow Image docs https://pillow.readthedocs.io/en/stable/reference/Image.html
